Misa Dimensions
Examples of Misa Dimensions below
- Over 200 combinations available
- Larger sizes are available
- Changes on these dimensions are available
- Please contact us to discuss your individual requirements
Chiller with no Floor
| MODEL | DIMENSIONS |
|
1A S6 |
1350 x 1350 x 2090mm HIGH or 2490mm HIGH |
|
2A S6 |
1750 x 1350 x 2090mm HIGH or 2490mm HIGH |
|
3A S6 |
2150 x 1350 x 2090mm HIGH or 2490mm HIGH |
|
4A S6 |
2550 x 1350 x 2090mm HIGH or 2490mm HIGH |
|
5A S6 |
2950 x 1350 x 2090mm HIGH or 2490mm HIGH |
|
2B S6 |
1750 x 1750 x 2090mm HIGH or 2490mm HIGH |
|
3B S6 |
2150 x 1750 x 2090mm HIGH or 2490mm HIGH |
|
4B S6 |
2550 x 1750 x 2090mm HIGH or 2490mm HIGH |
|
5B S6 |
2950 x 1750 x 2090mm HIGH or 2490mm HIGH |
|
3C S6 |
2150 x 2150 x 2090mm HIGH or 2490mm HIGH |
|
4C S6 |
2550 x 2150 x 2090mm HIGH or 2490mm HIGH |
|
5C S6 |
2950 x 2150 x 2090mm HIGH or 2490mm HIGH |
|
4D S6 |
2550 x 2550 x 2090mm HIGH or 2490mm HIGH |
|
5D S6 |
2950 x 2550 x 2090mm HIGH or 2490mm HIGH |
|
5E S6 |
2950 x 2950 x 2090mm HIGH or 2490mm HIGH |
|
6E S6 |
3350 x 3350 x 2090mm HIGH or 2490mm HIGH |
Chiller with Floor
| MODEL | DIMENSIONS |
|
1A F S6 |
1350 x 1350 x 2150mm HIGH or 2550mm HIGH |
|
2A F S6 |
1750 x 1350 x 2150mm HIGH or 2550mm HIGH |
|
3A F S6 |
2150 x 1350 x 2150mm HIGH or 2550mm HIGH |
|
4A F S6 |
2550 x 1350 x 2150mm HIGH or 2550mm HIGH |
|
5A F S6 |
2950 x 1350 x 2150mm HIGH or 2550mm HIGH |
|
2B F S6 |
1750 x 1750 x 2150mm HIGH or 2550mm HIGH |
|
3B F S6 |
2150 x 1750 x 2150mm HIGH or 2550mm HIGH |
|
4B F S6 |
2550 x 1750 x 2150mm HIGH or 2550mm HIGH |
|
5B F S6 |
2950 x 1750 x 2150mm HIGH or 2550mm HIGH |
|
3C F S6 |
2150 x 2150 x 2150mm HIGH or 2550mm HIGH |
|
4C F S6 |
2550 x 2150 x 2150mm HIGH or 2550mm HIGH |
|
5C F S6 |
2950 x 2150 x 2150mm HIGH or 2550mm HIGH |
|
4D F S6 |
2550 x 2550 x 2150mm HIGH or 2550mm HIGH |
|
5D F S6 |
2950 x 2550 x 2150mm HIGH or 2550mm HIGH |
|
5E F S6 |
2950 x 2950 x 2150mm HIGH or 2550mm HIGH |
|
6E F S6 |
3350 x 3350 x 2150mm HIGH or 2550mm HIGH |
Freezer with Floor
| MODEL | DIMENSIONS |
|
1A S10 |
1430 x 1430 x 2270mm HIGH or 2670mm HIGH |
|
2A S10 |
1830 x 1430 x 2270mm HIGH or 2670mm HIGH |
|
3A S10 |
2230 x 1430 x 2270mm HIGH or 2670mm HIGH |
|
4A S10 |
2630 x 1430 x 2270mm HIGH or 2670mm HIGH |
|
5A S10 |
3030 x 1430 x 2270mm HIGH or 2670mm HIGH |
|
2B S10 |
1830 x 1830 x 2270mm HIGH or 2670mm HIGH |
|
3B S10 |
2230 x 1830 x 2270mm HIGH or 2670mm HIGH |
|
4B S10 |
2630 x 1830 x 2270mm HIGH or 2670mm HIGH |
|
5B S10 |
3030 x 1830 x 2270mm HIGH or 2670mm HIGH |
|
3C S10 |
2230 x 2230 x 2270mm HIGH or 2670mm HIGH |
|
4C S10 |
2630 x 2230 x 2270mm HIGH or 2670mm HIGH |
|
5C S10 |
3030 x 2230 x 2270mm HIGH or 2670mm HIGH |
|
4D S10 |
2630 x 2630 x 2270mm HIGH or 2670mm HIGH |
|
5D S10 |
3030 x 2630 x 2270mm HIGH or 2670mm HIGH |
|
5E S10 |
3030 x 3030 x 2270mm HIGH or 2670mm HIGH |
|
6E S10 |
3430 x 3430 x 2270mm HIGH or 2670mm HIGH |
